Shockwave S5-LW Marine Seat Suspension

$826.67 USD

Shockwave S5-LW lightweight marine suspension base, an entry-level option for light seas on freshwater lakes or ocean cabin boats. Anodized A360 cast aluminum with 304 stainless hardware and an air-sprung shock with adjustable rebound; supports under 250 lbs.

Description

Shockwave S5-LW Marine Seat Suspension

The Shockwave S5-LW lightweight marine suspension base is Shockwave’s entry-level recreational suspension option. Designed to mitigate the shock of wave impact in light seas on freshwater lakes or cabin boats on the ocean.

Made from anodized A360 cast aluminum that has been powder coated and fitted with stainless steel hardware, the S5-LW suspension base utilizes a three-link forward action suspension design.

Fitted with an X-Fusion O2 PRO R air sprung shock with adjustable rebound, suspension travel is 4-inch vertical and 1.5-inch forward, mitigating deceleration associated with wave impact



Height 8.6in (218mm)
Width 12.0in (306mm)
Length 14.3in (363mm)
Weight 17.3 lbs (7.86 kg)
Weight Capacity Under 250 lbs (113.4 kg)



SW-07982_S5-AL_Drill_Plate_REV01

Shockwave_S5-LW__Bolt-Pattern

Shockwave_S5-LW__Specs

  • Designed and manufactured in Canada
  • Custom tuned and valved marine X-Fusion O2 R, air spring and shock with adjustable rebound
  • Surge protection: Suspension travel is 4-inch vertical and 1.5-inch forward, mitigating deceleration associated with wave impacts
  • 3-Link Forward Action
  • Anodized A360 Cast Aluminum, 304 SS Hardware, Powder Coated
  • Minimal parts count and simple construction
  • Easy to mount and adapt to current seating



The S5-LW suspension base is most often found on fishing boats, coastal cruisers, ski/wake boats, guide boats, fisheries boats, whale watching boats, crew boats and yacht tenders. Due to its universal design, the S5-LW can be fitted to almost any boat and any seat.

Additional information

Color

Black, White
