Description
Engineered for high-quality audio reproduction with innovative design aesthetics, Fusion’s new FM Series flush mount marine subwoofers are designed to deliver high-quality bass to your vessel in a sleek and minimalistic form factor to meet the latest boat design trends.
Featuring an intelligent mounting system for non-intrusive, easy installation, the FM Series subwoofers are designed to be flush mounted with a mounting flange no thicker than 3mm [1/8″] for a premium, visually-appealing, near-flat finish.
With an IP65 weatherproof rating, True-Marine accreditation and an industry-leading 3-year warranty, you can enjoy peace of mind that your FM Series subwoofers are built to last on board season after season.
Features:
Optimized 2.1 Configuration: When connected with a pair of FM Series speakers and a 2 Ohm stereo stable Fusion Multi-Zone stereo with DSP, you have the option of creating a 2.1 audio zone to simplify installation and reduce system cost by adding bass without the need for an external amplifier.
Quality Audio Reproduction: Enjoy quality low frequency audio at any volume level.
Innovative Design Aesthetics: Designed with a low profile, near-flat installation for a visually appealing finish, the FM Series will complement the aesthetics of any vessel.
Non-Intrusive Mounting System: The FM Series uses ‘speaker legs’ that keep the subwoofer in place without the need to create any screw holes in your vessel.
True-Marine Designed and Engineered: Extensively tested to perform in the harsh marine environment, the FM Series carry an IP65 weatherproof rating along with True-Marine accreditation.
Designed To Comply With ISO12216: Tested to international standards for pressure and watertightness, it recognizes the FM Series are designed and built to the highest industry standards for quality and robustness.
Specifications:
|
Subwoofer Size |
10″ |
|
Peak Power |
400 Watts |
|
RMS Power Rating |
120 Watts |
|
Efficiency (1W/1M) |
87 dB |
|
Frequency Response |
30 Hz – 2 kHz |
|
Nominal Impedance |
4 Ohms |
|
Recommended Amplifier Power (RMS) |
40 – 300 W/Ch |
|
Cone / Surround Material |
Polypropylene with rubber surround |
|
Mounting Diameter Clearance |
269mm [10-9/16″] |
|
Mounting Depth Clearance |
140mm [5-1/2″] |
|
Optimum Enclosure Volume (Sealed enclosure, fully filled with absorption material) |
40L |
|
Operating Temperature Range |
0 to 50°C (32 to 122°F) |
|
Storage Temperature Range |
-20 to 70°C (-4 to 158°F) |
|
Water and Dust Resistance (IP rating) |
IP65 |
|
Subwoofer Dimensions: Length x Height x Depth |
Ø 284mm x 137mm [Ø 11-3/16″ x 5-3/8″] |
|
Warranty |
3 years |
