Description
Introducing the world-class Fusion 755 Marine Entertainment Series, the pinnacle of marine audio engineering, which delivers unparalleled sound performance and media integration.
Featuring DVD/CD playback with electronic shock protection, hdmi connection and support for the latest Apple iOS, MTP Windows/Android and USB media devices, including Bluetooth A2DP/AVRCP audio streaming capabilities, support for advanced Fusion-Link NMEA 2000/Ethernet/Wi-Fi/Bluetooth connectivity, the Fusion 755 Marine Entertainment System is the next generation in the Fusion dynasty.
Features:
Marine-Ready DVD Player – Play your favorite DVD or CD in the comfort of your cabin. An hdmi connector is utilized for easy ‘plug-and-play’ compatibility with any supported TV or monitor, with ARC functionality to stream audio from the connected television to the Fusion stereo.
Fusion-Link Control (Wired) – Direct stereo control from a compatible Multi-Function Display (MFD) or NRX series wired remote control is available when utilizing an existing NMEA 2000 or Ethernet network.
Fusion-Link Control (Wireless) – Download the FREE Apple or Android Fusion-Link remote control app from the Apple App Store or Google Play Store to control your on-board entertainment experience from a compatible Apple or Android device. Wireless Fusion-Link control is available over Bluetooth and Wi-Fi (Note: Wi-Fi control requires a wireless Ethernet router). Fusion-Link Lite is available for download from the Garmin Connect IQ Store to enable wireless control via ANT technology from your compatible Garmin watch.
A2DP/AVRCP Bluetooth® Streaming – Stream your family’s favorite soundtrack from any compatible device, with track, album and artist info displayed, with navigation available from the stereo or connected device.
Apple iOS and MTP Android/Windows Media Playback – Unparalleled support of the world’s most popular media devices, and the smartest interface for browsing your music library.
Multi-Zone Technology – Four independent audio zones are available, each with advanced localized menu controls, including zone naming. Note: Line Out Zones require additional amplification.
Optically Bonded LCD – A color widescreen LCD display, optically bonded to improve durability and optimized for daylight viewing.
Side-Fin Cooling – Amplifier components are optimally configured for the side-fin aluminium heat sink, producing greater thermal efficiency.
Glass Filled Composite Chassis – Structurally rigid and incredibly lightweight, this improves environmental protection and electrically isolates the chassis for complete reliability.
Class-D Amplifier – Provides higher RMS output than a standard stereo, for louder and clearer audio while drawing less current.
True-Marine Designed and Engineered – Extensively tested to perform in the harsh marine environment.
| Tuner | AM/FM with RDS where available |
| Tuner Region | USA – Australasia – Europe – Japan |
| Multi-Language User Interface | English, French, German, Spanish, Dutch, Italian |
| Peak Power | 280W Max (@ 2 Ω) |
| Amplifier | Class-D: 4 x 26 W rms @ 14.1Vdc input, 4Ω, ≤ 10% THD+N. 4 x 43 W rms @ 14.4Vdc input, 2 Ω, ≤ 10% THD+N |
| Audio Zones | 4 Zones (Zone 1 & 2 powered by internal amplifier) + 4 Line Out zones |
| Nameable Zones | Yes – Up to 10 characters per zone |
| Line Out | 4 (1 x L + R Per zone, all require amplification) |
| Sub Out | 4 (1 per zone, all require amplification) |
| Auxiliary Inputs | 2 x stereo RCA inputs (AUX1, AUX2) |
| iPod/iPhone | Made for iPod and iPhone |
| Album Art | Available via USB on supported Apple, MTP (Android/Windows) and USB flash drive devices |
| Display | 16:9 WQVGA color widescreen optically bonded LCD |
| NMEA 2000 | NMEA 2000 Certified LEN: 1 |
| Fusion-Link | Compatible with NRX Series wired remote and supported Multi-Function Displays (MFDs) for wired control via NMEA 2000 or Ethernet (visit www.fusion-link.com for compatible MFDs). Wireless control is available with the Fusion-Link remote control app, available for free download for compatible Apple and Android devices. |
| Bluetooth | A2DP audio streaming with AVRCP support (album art is not supported). |
| USB | 1 x USB connector |
| MTP (Media Transfer Protocol) | Support for compatible Windows & Android media devices via USB |
| Audio/Video/USB Format | MP3, M4A, FLAC, CDA, DVD |
| SiriusXM-Ready™ | (USA Only.) Requires SiriusXM Connect vehicle tuner (sold separately). For more information visit www.siriusxm.com. |
| DVD Playback | hdmi connector outputting standard definition 576i for DVD playback |
| CD Playback | CD/CD-R disks supported |
| Water Resistance (IP Rating) | 360° IPX5 water resistant fully sealed chassis |
| Chassis | Electrically isolated Glass Filled Composite with Aluminum Heat Sink |
| DAB+ Ready | MS-DAB100A is required for DAB support, only available where DAB and DAB+ is broadcast |
| Compatible Apple Devices | iPhone X, iPhone 8, iPhone 8 Plus, iPhone 7, iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus, iPhone 6, iPhone 6 Plus, iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPod Touch (5th and 6th gen) |
| Dimensions: Length x Height x Depth (Front Panel incl. Volume Encoder) | 216mm x 78mm x 35mm [8-1/2″ x 3-1/16″ x 1-3/8″] |
| Mounting Dimensions: Height x Depth | 52mm x 177mm [2-1/16″ x 7″] |
