Description
Garmin STRIKER Vivid 7cv with GT20-TM Transducer
See fish and structure in maximum detail when you pick your display color, your location and your sonar for your day on the water with the STRIKER Vivid 7cv fishfinder with transducer.
CLEAR, COLORFUL SONAR
Choose from 7 new vivid color options to see fish and structure in maximum contrast and clarity on your 7” fishfinder.
BUILT-IN SONAR
Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.
WAYPOINT MARKING
To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.
HIGH-SENSITIVITY GPS
Plan and create routes and view your boat’s speed on your fishfinder using high-sensitivity GPS.
QUICKDRAW CONTOURS
Nobody knows the waters you fish better than you. With the STRIKER Vivid 7cv fishfinder, you can store up to 2 million acres of maps with 1’ contours.
WI-FI CONNECTIVITY
Connect to the ActiveCaptain app to transfer waypoints, receive smart notifications (including software update notifications) and access the Garmin Quickdraw Community.
INCLUDED HARDWARE
The STRIKER Vivid 7cv fishfinder includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.
Specifications:
| Physical dimensions | 9.3” x 5.5” x 2.3” (23.5 x 14.0 x 5.8 cm) |
| Water rating | IPX7 |
| Display resolution | 800 x 480 pixels |
| Weight | 1.7 lbs (0.8 kg) |
| Display type | WVGA color |
| Additional |
|
| Water temperature sensor included | Yes |
| Dual-frequency (50/200 kHz) sonar capable | Yes |
| Transmit power | 500 W (RMS) |
| Adjustable depth line (measures depth of underwater objects) | Yes |
| A-scope (real time display of fish passing through transducer beam) | Yes |
| Frequencies supported |
Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü 260/455/800 kHz |
| Water temperature log and graph | Yes |
| Bottom lock (shows return from the bottom up) | Yes |
| Audible alarms | Yes |
| Dual-beam (77/200 kHz) sonar capable | Yes |
| Fish Symbol ID (helps identify fish targets) | Yes |
| AutoGain Technology (minimizes clutter, maximizes targets) | Yes |
| Ultrascroll (displays fish targets at higher boat speeds) | Yes |
| Split-screen zoom | Yes |
